Construction | |
| Construction Chassis | Plastic Chassis with Aluminum Heatsink |
| Mounting Configuration | Panel, Wall VESA 75 |
| Protection Level of Chassis | IP65, NEMA4 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 8.4 " |
| Maximum resolution | 800x600 Dots |
CPU | |
| Processor Installed | ARM Cortex A8 |
| Max CPU frequency | 1 GHz |
Memory | |
| Default on Board Memory | 0.5 GB |
Installed drive | |
| Flash Memory Capacity | 256 MB |
| EEPROM Memory Capacity | 16 kB |
| MRAM Memory Capacity | 128 kB |
Drive interfaces | |
| SD Slots | 1 |
Software | |
| Operating System Installed | Windows CE 7.0 |
| Programming Method | IEC 61131-3, C#, C |
| Development Software | Win-GRAF |
Ethernet | |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-485 | 1 |
| USB Total | 2 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus TCP client, Modbus RTU slave, Modbus RTU master, Modbus UDP master, Modbus ASCII master, DCON master |
Additional Functions | |
| Watchdog timer type | Hardware |
Dimensions and weight | |
| Width | 249 mm |
| Depth | 64 mm |
| Height | 207 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
| Power over Ethernet (PoE) | PoE, IEEE 802.3af |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
