VPD-130N-H-V

Ціна за запитом
3.5" touch HMI device with RS-232/RS-485, USB, RTC, Rubber Keypad, 12-48VDC

Specification

Construction

Construction ChassisPlastic Chassis
Mounting ConfigurationPanel, DIN-Rail mount
Protection Level of ChassisIP65

Display

Display TypeLCD TFT
Diagonal3.5 "
Maximum resolution320x240 Dots
Brightness270 Cd/m2

Touch Screen

Touch Screen TypeResistive

Installed drive

Flash Memory Capacity16 MB

Interfaces

COM Total1
RS-232/4851

Supported Protocols

Industrial ProtocolsModbus RTU slave, Modbus RTU master, DCON master

Software

Development SoftwareHMIWorks
Programming MethodLadder Diagram, C/C++

System Power Input

Input Voltage DC12...48 V

Dimensions and weight

Width103 mm
Depth53 mm
Height103 mm

Operating Conditions

Operating Temperature-20...50 °C

Standards and Certifications

CertificationsCE, FCC

Files

Documentation

📄 Datasheet VPD-130(N)-H-V
