Camera | |
| Form Factor | Mini |
| Video Analytics Functions | Motion Detection, Camera Tamper |
| Max Resolution Frame rate | 30 fps |
Ethernet | |
| 10/100 Mbit/s | 1 |
Supported Protocols | |
| Managment Protocols | SMTP, SNMPv1/v2c/v3, HTTP, Telnet, TFTP, QoS, TCP, UDP, DHCP, DNS, IGMP, FTP, NTP, DDNS, ARP |
| Reservation protocols | RSTP |
| Security Protocols | Password Protection, IP Address Filtering, IEEE 802.1X Network Access Control, HTTPS, SSH, ICMP |
Connectors | |
| Connectors | 4-pin M12 D-code female, RCA |
System Power Input | |
| Power over Ethernet (PoE) | PoE |
| Power Consumption | 6 W |
Dimensions and weight | |
| Height | 47 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMI | FCC Part 15, EN 55022 Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8 |
| Freefall | IEC 60068-2-32 |
| Rolling Stock | EN 50155, EN 45545 |
| Safety | UL 60950-1 |
| Vandal Resistance | EN 62262, IK09 level |
| Vibration And Shock | IEC 61373 |
