Camera |
| Form Factor | Mini |
| Video Analytics Functions | Motion Detection, Camera Tamper |
| Max Resolution Frame rate | 30 fps |
Supported Protocols |
| Managment Protocols | SMTP, SNMPv1/v2c/v3, HTTP, TFTP, QoS, IGMPv1/v2/v3, UDP, DHCP, DNS, NTP, DDNS, ARP, TCP/IP |
| Reservation protocols | RSTP |
| Security Protocols | Password Protection, IP Address Filtering, IEEE 802.1X Network Access Control, HTTPS, SSH, ICMP |
Digital Input |
| Total channels of digital input | 1 |
Connectors |
| Connectors | 4-pin M12 D-code female, 5-pin M12 male |
System Power Input |
| Power over Ethernet (PoE) | PoE |
| Power Consumption | 8.1 W |
Dimensions and weight |
| Width | 110 mm |
| Depth | 115.5 mm |
| Height | 61.8 mm |
Operating Conditions |
| Operating Temperature | -40...70 °C |
Standards and Certifications |
| Certifications | CE, FCC |
| EMI | FCC Part 15, EN 55022 Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| Freefall | IEC 60068-2-32 |
| Rolling Stock | EN 50155 |
| Safety | UL 60950-1 |
| Vandal Resistance | EN 62262, IK08 level |
| Vibration And Shock | IEC 61373 |
