Camera | |
| Form Factor | Dome |
| Day&Night Mode | IR Cut Filter Remove |
| Video Analytics Functions | Motion Detection, Camera Tamper |
| Max Resolution Frame rate | 30 fps |
Ethernet | |
| 10/100 Mbit/s | 1 |
Supported Protocols | |
| Managment Protocols | SMTP, SNMPv1/v2c/v3, HTTP, Telnet, TFTP, QoS, TCP, UDP, DHCP, DNS, IGMP, FTP, NTP, DDNS, ARP |
| Reservation protocols | RSTP |
| Security Protocols | Password Protection, IP Address Filtering, IEEE 802.1X Network Access Control, HTTPS, SSH, ICMP |
Digital Input | |
| Total channels of digital input | 1 |
Connectors | |
| Connectors | 4-pin M12 D-code female, 5-pin M12 male |
System Power Input | |
| Power over Ethernet (PoE) | PoE |
Dimensions and weight | |
| Width | 125 mm |
| Depth | 125 mm |
| Height | 120.7 mm |
Operating Conditions | |
| Operating Temperature | -25...55 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| Corrosion resistance | ASTM B117 |
| EMI | FCC Part 15, EN 55022 Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| Freefall | IEC 60068-2-32 |
| Rolling Stock | EN 50155, EN 50121-3-2 |
| Safety | UL 60950-1 |
| Vandal Resistance | EN 62262, IK10 level |
| Vibration And Shock | IEC 61373 |
