System Architecture | |
| Form Factor | 2.5" |
Construction | |
| Type | Fanless |
CPU | |
| CPU Support Type | Vortex86 |
| Processor Installed | Vortex86SX |
| Max CPU frequency | 0.3 GHz |
Chipset | |
| Chipset | Vortex86 System-on-Chip |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.13 GB |
| Maximum Memory | 0.25 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | XGI Volari Z9S |
| Interfaces | LVDS, VGA |
Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/485 | 1 |
| USB Total | 2 |
| USB 2.0 | 2 |
Extension Slots | |
| ISA | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 44-pin IDE, 4x10-pin RS-232, 10-pin USB 2.0, 16-pin LVDS, 3-pin RS-485, 6-pin JTAG, 20-pin GPIO, 5-pin KB, 5-pin MS, 10-pin VGA |
| Connectors | RJ45 Ethernet |
Dimensions and weight | |
| Width | 66 mm |
| Length | 100 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
