Specification
System Architecture | |
| Form Factor | Half-Size PICMG |
Construction | |
| Type | Fanless |
CPU | |
| CPU Support Type | Vortex86 |
| Processor Installed | Vortex86SX |
| Socket | CPU onboard |
| Max CPU frequency | 0.3 GHz |
| Number of CPU | 1 |
Chipset | |
| Chipset | Vortex86SX |
Memory | |
| Form-factor | DDR2 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 0.25 GB |
| Maximum Memory | 0.25 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | XGI Volari Z9S |
| Interfaces | LVDS, VGA |
Ethernet | |
| Controller Type | Integrated with Chipset |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 8 |
| RS-232 | 7 |
| RS-232/422/485 | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 44-pin IDE, USB 2.0, 34-pin FDD, 10-pin RS-232, 16-pin LVDS, 44-pin LCD, 3-pin RS-485, 6-pin JTAG, 20-pin GPIO, 10-pin VGA |
| Connectors | RJ45 Ethernet, DC Input |
Software | |
| Operating System Compatibility | MS DOS, Windows CE 5.0, Linux OS |
Dimensions and weight | |
| Width | 102 mm |
| Length | 144 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
