Construction | |
| Construction Chassis | Rubber |
| Protection Level of Chassis | IP67 |
CPU | |
| Processor Installed | Intel Atom E3815 |
| Max CPU frequency | 1.46 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Default on Board Memory | 2 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| RS-485 | 1 |
Industrial Interfaces | |
| CAN Port | 1 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 2 |
Additional Functions | |
| GPS | GPS |
Connectors | |
| Connectors | 2xDB9, DB15 VGA, HDMI, Mic In, Line Out, 3xM12 |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Windows Embedded Standard 8, Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 56.5 mm |
| Height | 185 mm |
| Depth | 167 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration |
| Automotive | e13 Mark |
| Vibration And Shock | IEC 60068-2-64 |
