Construction | |
| Construction Chassis | Aluminium Chassis |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom E3950 |
| Max CPU frequency | 2 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 2 |
| RS-422/485 | 1 |
| USB Total | 3 |
| USB 2.0 | 1 |
| USB v3.x | 2 |
Industrial Interfaces | |
| CAN Port | 1 |
Storage Cage | |
| 2.5" Cage External | 2 |
Extension Slots | |
| Total | 4 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 3 |
| SIM Card slots | 4 |
Additional Functions | |
| GPS | GPS |
Connectors | |
| Connectors | DB15 VGA, HDMI, 3xRJ45 Ethernet, 3xUSB, DC input (terminal block), 1xSMA (GPS antenna connector), 2xLine Out, 2xMic In, 5xSMA |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Installed | Windows 10 |
Dimensions and weight | |
| Width | 259 mm |
| Height | 50 mm |
| Depth | 196 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
