Construction | |
| Construction Chassis | Metal Chassis |
| Protection Level of Chassis | IP66 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 12.1 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 700 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Celeron 3955U |
| Max CPU frequency | 2 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n/ac |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB 2.0 | 1 |
Industrial Interfaces | |
| CAN Port | 1 |
Drive interfaces | |
| M.2 | 1 |
| SD Slots | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| 1st Storage Capacity | 64 GB |
Antenna characteristics | |
| Cellular interfaces | 4G |
Additional Functions | |
| GPS | GPS |
Connectors | |
| Connectors | RJ45 Ethernet, 2xUSB, DC Input, DB15 CAN Bus, Audio In |
System Power Input | |
| Input Voltage DC | 9...60 V |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Windows Embedded Professional 7 (64 bit) |
Operating Conditions | |
| Operating Temperature | -30...55 °C |
Standards and Certifications | |
| MIL-STD-810 | MIL-STD-810G Test Method 509.5 Salt Fog, MIL-STD-810G Test Method 514.6 Vibration |
