Construction | |
| Mounting Configuration | Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP54 |
Display | |
| Diagonal | 5 " |
| Maximum resolution | 800x480 Dots |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 500~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | ARM Cortex A8 TI AM3354 |
| Max CPU frequency | 1 GHz |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.5 GB |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| USB Total | 1 |
Drive interfaces | |
| MicroSD | 1 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 1 GB |
Connectors | |
| Connectors | RJ45 Ethernet, MicroSD card slot, USB type A |
System Power Input | |
| Input Voltage DC | 12...12 V |
Dimensions and weight | |
| Width | 138 mm |
| Height | 138 mm |
| Depth | 29 mm |
Operating Conditions | |
| Operating Temperature | 0...55 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
