Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Panel, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 7 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 320 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | NXP i.MX6 dual-core |
| Socket | CPU onboard |
| Max CPU frequency | 1 GHz |
Chipset | |
| Chipset | SoC |
Memory | |
| Form-factor | DDR3 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 1 GB |
| Maximum Memory | 2 GB |
| Assembly | Fixed on Board |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-485 | 1 |
| USB Total | 2 |
| USB 2.0 | 2 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 8 GB |
LED / Controls | |
| LED | 1xHDD LED |
| Controls | 1xReset |
Connectors | |
| Connectors | RJ45 Ethernet, 1xUSB, 1xMicro USB, 1xCAN Bus, DB9, DC input (terminal block) |
System Power Input | |
| Input Voltage DC | 12...24 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 50 W |
Software | |
| Operating System Compatibility | Linux OS, Ubuntu |
Dimensions and weight | |
| Width | 185 mm |
| Height | 128 mm |
| Depth | 46 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Humidity | 10-90% |
Standards and Certifications | |
| Certifications | CE/FCC |
