Construction | |
| Mounting Configuration | Built-in, Panel, Wall |
| Protection Level of Chassis | IP65 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.1 " |
| Maximum resolution | 1024x600 Dots |
| Brightness | 200 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | ARM Cortex A9 |
| Max CPU frequency | 1 GHz |
Memory | |
| Form-factor | DDR3 |
| ECC | No |
| Default on Board Memory | 1 GB |
| Maximum Memory | 2 GB |
| Assembly | Fixed on Board |
Ethernet | |
| Total Ethernet | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB 2.0 | 1 |
Industrial Interfaces | |
| CAN Port | 1 |
Drive interfaces | |
| MicroSD | 1 |
Connectors | |
| Connectors | DB9, RJ45 Ethernet, 2xUSB, MicroSD card slot |
System Power Input | |
| Input Voltage DC | 12...12 V |
| Power Consumption | 10 W |
Software | |
| Operating System Compatibility | Linux OS, Ubuntu |
| Operating System Installed | Android |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
