Construction | |
| Construction Chassis | ABS plastic chassis |
| Mounting Configuration | Desktop, Panel, Wall, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.1 " |
| Maximum resolution | 1280x800 Dots |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | ARM Cortex A9 |
| Max CPU frequency | 1 GHz |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 1 GB |
| Maximum Memory | 2 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Broadcom BCM57780 |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 3 |
| USB 2.0 | 2 |
Drive interfaces | |
| mSATA | 1 |
| MicroSD | 1 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 16 GB |
LED / Controls | |
| LED | Power LED, Programmable LED Light Bar Indicator |
| Controls | On/Off |
Connectors | |
| Connectors | 2xDB9, RJ45 Ethernet, 3xUSB, DC input (terminal block), SD card slot |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Linux OS |
| Operating System Installed | Android |
Dimensions and weight | |
| Width | 263.28 mm |
| Height | 171 mm |
| Depth | 35.7 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
