Construction | |
| Mounting Configuration | Wall VESA 75 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.1 " |
| Maximum resolution | 1280x800 Dots |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 2 GB |
Ethernet | |
| Controller Type | Intel i210-AT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB 2.0 | 1 |
| USB v3.x | 1 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 64 GB |
Connectors | |
| Connectors | HDMI |
System Power Input | |
| Input Voltage DC | 12...12 V |
Dimensions and weight | |
| Width | 199 mm |
| Height | 293 mm |
| Depth | 62 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
