Construction | |
| Mounting Configuration | Panel, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x600 Dots |
| Brightness | 450 Cd/m2 |
| Contrast Ratio | 500~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 2 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Controller Type | Intel WG82574L |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 1 |
| USB 2.0 | 1 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 64 GB |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | RJ45 Ethernet, Audio Out |
System Power Input | |
| Input Voltage DC | 12...12 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows IoT Enterprise 10, Windows Embedded 8.1 Industry |
Dimensions and weight | |
| Width | 268 mm |
| Height | 172 mm |
| Depth | 35.7 mm |
Operating Conditions | |
| Vibration | 1.60/1.96/2.18 g rms for XYZ / 5-500Hz |
