Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP44 |
Display | |
| Diagonal | 10.1 " |
| Maximum resolution | 1280x800 Dots |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11ac/a/b/g/n |
Interfaces | |
| COM Total | 3 |
| RS-232 | 2 |
| RS-422 | 1 |
| USB Total | 1 |
| USB 2.0 | 1 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 128 GB |
Antenna characteristics | |
| Cellular interfaces | 3G |
Additional Functions | |
| GPS | GPS |
Connectors | |
| Connectors | RJ45 Ethernet, DC Input |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows 7 Professional, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 263.3 mm |
| Height | 173.6 mm |
| Depth | 40.2 mm |
Operating Conditions | |
| Operating Temperature | -15...55 °C |
