Construction | |
| Construction Chassis | Open Frame, Metal Chassis |
| Mounting Configuration | Panel, Wall VESA 75 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.1 " |
| Maximum resolution | 1920x1200 Dots |
| Aspect Ratio | 16:10 |
| Brightness | 700 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Elkhart Lake |
| Processor Installed | Celeron N6210 |
| Socket | FCBGA1493 |
| Max CPU frequency | 3 GHz |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| SATA 3 | 1 |
| M.2 | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| Drive Interface | SATA |
| 1st Storage Capacity | 128 GB |
Extension Slots | |
| Total | 2 |
| M.2 | 2 |
| M.2 Form Factor | 2242 M, 2230 E |
LED / Controls | |
| LED | 1xHDD LED, Power LED |
Connectors | |
| Connectors | 2xDB9, HDMI, 2xRJ45 Ethernet, 2xUSB, DC Input |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 50 W |
Software | |
| Operating System Compatibility | Ubuntu, Windows IoT Enterprise 10, Windows 11 |
Dimensions and weight | |
| Width | 264 mm |
| Height | 190 mm |
| Depth | 48 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Humidity | 10-90% |
Standards and Certifications | |
| Certifications | CE/FCC |
