Construction | |
| Construction Chassis | Metal Chassis with Plastic component |
| Mounting Configuration | Panel |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15.6 " |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | ARM Cortex-A53 |
Chipset | |
| Chipset | SoC |
Memory | |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 4 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 3 |
| USB 2.0 | 3 |
Connectors | |
| Connectors | DB9, RJ45 Ethernet, 2xUSB, DC input (terminal block), 1xMicro USB, MicroSD card slot, Micro HDMI |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 50 W |
Software | |
| Operating System Compatibility | Android |
Dimensions and weight | |
| Width | 388 mm |
| Height | 260 mm |
| Depth | 62.5 mm |
Standards and Certifications | |
| Certifications | CE/FCC |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
