Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall VESA 75, VESA 200x100 |
| Material Front Side (Panel) | Plastic |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15.6 " |
| Maximum resolution | 1920x1080 Dots |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
| Interface | USB |
LED / Controls | |
| LED | 1xOn/Off LED |
| Controls | On/Off |
Connectors | |
| Connectors | DB15 VGA, HDMI, Audio, Console Port USB |
System Power Input | |
| Input Voltage DC | 12...12 V |
| Power Consumption | 10 W |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Dimensions and weight | |
| Width | 387.8 mm |
| Height | 232.9 mm |
| Depth | 40 mm |
Standards and Certifications | |
| Certifications | CE, FCC, EN 60601 |
