Construction | |
| Construction Chassis | Open Frame |
| Mounting Configuration | Panel |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 21.5 " |
| Maximum resolution | 1920x1080 Dots |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Socket | CPU onboard |
| Max CPU frequency | 2.16 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Default on Board Memory | 2 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Intel i210AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB 2.0 | 1 |
| USB v3.x | 1 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 64 GB |
LED / Controls | |
| Controls | Control Buttons |
Connectors | |
| Connectors | DB9, HDMI, 2xRJ45 Ethernet, 2xUSB, DC Input |
System Power Input | |
| Input Voltage DC | 12...12 V |
| Power Consumption | 60 W |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows IoT Enterprise 10, Windows Embedded 8.1 Industry |
Dimensions and weight | |
| Width | 552 mm |
| Height | 312.72 mm |
| Depth | 52.8 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Vibration | 2.18 g rms for XYZ/ 5-500Hz |
| Shock | 30g for 18ms |
Standards and Certifications | |
| Certifications | CE, FCC |
