Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall VESA 100, Panel |
| Protection Level of Front Side (Panel) | IP66 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 24 " |
| Maximum resolution | 1920x1080 Dots |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 3000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Core i5-1335U |
| Max CPU frequency | 4.6 GHz |
Memory | |
| Form-factor | DDR5 |
| Default on Board Memory | 8 GB |
| Maximum Memory | 32 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 2 |
| USB 2.0 | 1 |
| USB v3.x | 1 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| 1st Storage Capacity | 128 GB |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, KeyPad |
Connectors | |
| Connectors | 2xRJ45 Ethernet, 2xUSB, DC Input, DB9 |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows 7 Professional, Windows IoT Enterprise 10, Windows Embedded 8.1 Industry |
Operating Conditions | |
| Operating Temperature | -15...55 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| Marine grade | IACS-E10 |
| Safety | IEC 60945 (4th) |
