Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Panel, Wall VESA 100, VESA 200 |
| Protection Level of Front Side (Panel) | IP66 |
| Material Front Side (Panel) | Aluminum |
Display |
| Display Type | LCD TFT |
| Diagonal | 24 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 5000~1 |
| Input Interface | VGA, HDMI, DVI |
Touch Screen |
| Touch Screen Type | Capacitive |
| Interface | USB |
LED / Controls |
| LED | Power LED |
| Controls | On/Off, KeyPad |
Connectors |
| Connectors | DB15 VGA, HDMI, DC input (terminal block), 1xUSB, DB9, DVI |
Power Supply |
| Type of Power Supply | External power adapter AC/DC |
| Input Voltage DC | 9...36 V |
Operating Conditions |
| Operating Temperature | -15...55 °C |
| Humidity | 5-95% |
| Vibration | 0.7g@DNVGL CG0339 (Class A |
| Shock | 15G.11ms duration |
Dimensions and weight |
| Width | 595 mm |
| Height | 385 mm |
| Depth | 63.8 mm |
Standards and Certifications |
| Certifications | CE, FCC |
| Marine grade | IEC 60945 4th, DNV, IACS-E10 |
