Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | VESA 200 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fan |
Display | |
| Display Type | LCD TFT |
| Diagonal | 32 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 4000~1 |
| Input Interface | DisplayPort |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Alder Lake |
| Processor Installed | Intel Core i7-12700TE |
| Socket | LGA1700 |
| CPU Support Type | Core i7, Core i9 |
| Max CPU frequency | 4.6 GHz |
Chipset | |
| Chipset | Intel R680E |
Memory | |
| Form-factor | DDR5 |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 16 GB |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 2,5 Gbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| M.2 | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| Drive Interface | PCIe x4 |
| 1st Storage Capacity | 512 GB |
Extension Slots | |
| Total | 3 |
| PCI Express x16 | 1 |
| M.2 | 2 |
| M.2 Form Factor | 2280 M, 2230 E |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | AC Input, 2xRJ45 Ethernet, Mic In, Line Out, 4xUSB, Display Port, DB9 |
System Power Input | |
| Input Voltage AC | 80...264 V |
Software | |
| Operating System Compatibility | Windows 11, Windows 10, Ubuntu |
Dimensions and weight | |
| Width | 777.6 mm |
| Height | 477.6 mm |
| Depth | 73.3 mm |
Operating Conditions | |
| Operating Temperature | 0...55 °C |
| Humidity | 10-90% |
Standards and Certifications | |
| Certifications | CE/FCC |
