Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Panel, Wall, Yoke mounting, VESA 200 |
| Protection Level of Front Side (Panel) | IP65 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 32 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 300~1 |
CPU | |
| Processor Installed | Intel Core i7-7700T |
| Socket | CPU onboard |
| Max CPU frequency | 3.8 GHz |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek ALC883 |
Connectors | |
| Connectors | DB9, HDMI, 2xRJ45, 4xUSB, Mic In, Line In, DC Input, Display Port |
System Power Input | |
| Input Voltage DC | 24...24 V |
| Power Consumption | 100 W |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows 7 Professional, Windows IoT Enterprise 10, Windows Embedded 8.1 Industry |
Dimensions and weight | |
| Width | 777.58 mm |
| Height | 477.62 mm |
| Depth | 63 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Standards and Certifications | |
| Certifications | CE/FCC |
