Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Yoke mounting, VESA 200 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fan |
Display | |
| Display Type | LCD TFT |
| Diagonal | 43 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 3000~1 |
| Input Interface | HDMI, DisplayPort |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Coffee Lake Refresh |
| Processor Installed | Intel Core i5-9500TE |
| Socket | LGA1151 |
| Max CPU frequency | 2.2 GHz |
Chipset | |
| Chipset | Intel B360 |
Memory | |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
Drive interfaces | |
| RAID Levels | 1 |
| M.2 | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage Intenal | 2 |
Extension Slots | |
| Total | 2 |
| M.2 | 2 |
LED / Controls | |
| LED | 1xHDD LED, Power LED |
| Controls | On/Off, 1xReset |
Connectors | |
| Connectors | DB9, HDMI, 2xRJ45 Ethernet, Mic In, Line Out, DC Input, Display Port |
System Power Input | |
| Input Voltage DC | 24...24 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Ubuntu, Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 1028.8 mm |
| Height | 617 mm |
| Depth | 62.8 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
