Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Panel |
| Protection Level of Front Side (Panel) | IP66 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15.6 " |
| Maximum resolution | 1366x768 Dots |
| Aspect Ratio | 16:9 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Core i3-4010U |
| Socket | CPU onboard |
| Max CPU frequency | 1.7 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
Ethernet | |
| Controller Type | Intel i210 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB v3.x | 1 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| CFast Slots | 1 |
Installed drive | |
| Drive Type | SSD |
| Drive Interface | SATA |
| 1st Storage Capacity | 128 GB |
Connectors | |
| Connectors | 2xDB9, 2xHDMI, 2xRJ45 Ethernet, 1xUSB, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 19...29 V |
Software | |
| Operating System Installed | Windows 7 Professional |
Dimensions and weight | |
| Width | 419.7 mm |
| Height | 269 mm |
| Depth | 56.7 mm |
Operating Conditions | |
| Operating Temperature | 0...55 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| Safety | CCC, UL, BSMI |
