System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| СPU Generation/Family | Skylake, Kaby Lake |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel H110 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Realtek 8111F |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 6 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
Extension Slots | |
| Total | 2 |
| PCI Express x16 | 1 |
| Mini-PCI | 1 |
Connectors | |
| Internal Ports | 2xSATA 3, 4-pin (12V DC CPU), 24-pin ATX |
| Connectors | 2xDB9, DB15 VGA, HDMI, PS/2 Mouse, PS/2 Keyboard, 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
