System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron J1900 |
| Socket | CPU onboard |
| Max CPU frequency | 2.42 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | Soldered |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel Gen7 graphic engine |
| Interfaces | LVDS, VGA, iDP |
Ethernet | |
| Controller Type | Intel i210-IT, Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 3 |
| RS-422/485 | 1 |
| USB Total | 6 |
| USB 2.0 | 5 |
| USB v3.x | 1 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC662 HD |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 1x4-pin RS-422/485, 2x10-pin RS-232, 2x4-pin USB 2.0 |
| Connectors | DB9, DB15 VGA, LVDS, 2xRJ45 Ethernet, 2xUSB, Display Port |
Dimensions and weight | |
| Width | 146 mm |
| Length | 102 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
