System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron N5105 |
| Max CPU frequency | 2.9 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel UHD Graphics |
| Interfaces | DisplayPort, HDMI |
Ethernet | |
| Controller Type | Intel i225V |
| 2,5 Gbit/s | 3 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 12 |
Extension Slots | |
| SIM Card slots | 1 |
| M.2 | 2 |
Connectors | |
| Internal Ports | 2xCOM, 2xUSB 2.0 |
| Connectors | HDMI, 3xRJ45, 2xUSB, Display Port |
Dimensions and weight | |
| Width | 115 mm |
| Length | 165 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
