System Architecture | |
| Form Factor | 3.5" |
CPU | |
| CPU Support Type | rockchip |
| Processor Installed | Rockchip RK3568 |
| Max CPU frequency | 2 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | Soldered |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Fixed on Board |
Graphic | |
| Interfaces | HDMI, eDP |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232/485 | 2 |
| USB Total | 5 |
| USB 2.0 | 3 |
| USB v3.x | 2 |
Drive interfaces | |
| MicroSD | 1 |
Installed drive | |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 32 GB |
Extension Slots | |
| SIM Card slots | Nano SIM |
| M.2 | 1 |
| M.2 Form Factor | 3042 B, 3052 B |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | Line Out, Mic In, HDMI, 2xRJ45, 2xDB9, 5xUSB |
Software | |
| Operating System Compatibility | Android, Linux OS |
Dimensions and weight | |
| Width | 146 mm |
| Length | 102 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
| Humidity | 10-95% |
