System Architecture | |
| Form Factor | 3.5" |
CPU | |
| CPU Support Type | rockchip |
| Processor Installed | Rockchip RK3588 |
| Max CPU frequency | 2.4 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | Soldered |
| Default on Board Memory | 8 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Mali-G610 |
| Interfaces | LVDS, 3xHDMI |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
| 2,5 Gbit/s | 1 |
Interfaces | |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| SATA 3 | 1 |
Installed drive | |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 32 GB |
Extension Slots | |
| Total | 3 |
| M.2 | 2 |
Connectors | |
| Internal Ports | 4-pin Line-out, 4-pin Mic-in |
| Connectors | 4xUSB, 2xRJ45, 3xHDMI, LVDS, DC Input |
Software | |
| Operating System Compatibility | Android, Linux OS |
Dimensions and weight | |
| Width | 146 mm |
| Length | 102 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
| Humidity | 5-95% |
