System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Whiskey Lake |
| Processor Installed | Intel Core i7-8665UE |
| Socket | CPU onboard |
| Max CPU frequency | 4.4 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Interfaces | LVDS, 2xHDMI |
Ethernet | |
| Controller Type | Intel i211, Intel i219 |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 2xCOM, 2xUSB 2.0, 10-pin DIO, 40-pin LVDS |
| Connectors | 2xHDMI, 3xRJ45, 4xUSB |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 165 mm |
| Length | 115 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE |
