Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Panel, Wall |
CPU | |
| Processor Installed | Intel Celeron N3350 |
| CPU Support Type | Atom |
| Max CPU frequency | 2.4 GHz |
Memory | |
| Form-factor | DDR3L |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| USB Total | 6 |
| USB v3.x | 6 |
Audio | |
| Audio Controller | Realtek ALC892 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | HDMI, 6xUSB, Mic In, Line In, Line Out, Display Port |
System Power Input | |
| Input Voltage DC | 12...24 V |
Dimensions and weight | |
| Width | 200 mm |
| Height | 150 mm |
| Depth | 80 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
