Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Portable |
| Protection Level of Chassis | IP40 |
| Type | Fanless |
CPU | |
| CPU Support Type | Atom |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xDIMM |
| Maximum Memory | 8 GB |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
| MicroSD | 1 |
Extension Slots | |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB15 VGA, 2xUSB, Display Port |
System Power Input | |
| Input Voltage DC | 12...24 V |
Dimensions and weight | |
| Width | 150 mm |
| Height | 150 mm |
| Depth | 60 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Vibration | 5Grms/10~500Hz. IEC 60068-2-6 |
| Shock | 50G. 11msec. IEC 60068-2-27 |
Standards and Certifications | |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
