Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Wi-Fi | |
| Wi-Fi Standard | 802.11b/g |
| Quantity of Wi-Fi | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus UDP slave |
Digital Input | |
| Total channels of digital input | 8 |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 0~4 V |
| Level of Logic "1" | 10~50 V |
| Sink/Source | Dry: Source, Wet: Sink/Source |
| Isolation of Digital Input | 3750 V |
| Number of channels | 8 |
| Counter capacity | 32 Bit |
| Max frequency | 8 kHz |
Digital Output | |
| Total channels of digital output | 8 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 3.5~50 V |
| Max. load current | 700 mA |
Connectors | |
| Connectors | Screw Terminal |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 33 mm |
| Depth | 107 mm |
| Height | 127 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
| Humidity | 10-90% |
