Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Ethernet | |
| 10/100 Mbit/s | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus UDP slave |
Expansion Module | |
| io_type | multifunctional |
Analog Input | |
| Total channels of analog input | 8 |
| Number of Bits | 12 Bit |
| Current range | 0...20 mA, 4...20 mA |
| Sampling rate | 10 Hz |
| Differential channels | 8 |
Digital Output | |
| Total channels of digital output | 4 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 0~30 V |
| Max. load current | 400 mA |
| Output frequency range | 0~5 kHz |
Connectors | |
| Connectors | RJ45, Terminal block |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 80 mm |
| Depth | 25 mm |
| Height | 98 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
Standards and Certifications | |
| Certifications | FCC |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 61000-6-2, EN 55011, EN 61000-6-4 |
