Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Analog Input |
| Total channels of analog input | 2 |
| Number of Bits | 12 Bit |
| Voltage range | 0...10 V |
| Sampling rate | 5 Hz |
Digital Input |
| Total channels of digital input | 2 |
| Type | Dry contact |
| Max frequency | 3 kHz |
| Counter | 3KHz |
Digital Output |
| Total channels of digital output | 2 |
| Type | Electromagnitic relay |
| Relay (Form A) | 2 |
| Contact rating of relay (Form A) | 05A@120V AC, 1A@30V DC |
| Output frequency range | 0~3 kHz |
Wi-Fi |
| Wi-Fi Standard | 802.11b/g/n |
Expansion Module |
| io_type | di_do |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus UDP slave |
Connectors |
| Connectors | 1xMicro USB, Terminal block |
Additional Functions |
| Watchdog timer type | Hardware, Software |
System Power Input |
| Input Voltage DC | 0...5 V |
Dimensions and weight |
| Width | 80 mm |
| Depth | 25 mm |
| Height | 148 mm |
Operating Conditions |
| Operating Temperature | -25...70 °C |
Standards and Certifications |
| Certifications | FCC |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 61000-6-2, EN 55011, EN 61000-6-4 |
