Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Digital Input |
| Total channels of digital input | 4 |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 0~3 V |
| Level of Logic "1" | 10~30 V |
| Isolation of Digital Input | 3000 V |
| Max frequency | 3 kHz |
| Counter | 3KHz |
Digital Output |
| Total channels of digital output | 4 |
| Type | Open collector |
| Output voltage | 0~30 V |
| Max. load current | 400 mA |
| Output frequency range | 0~5 kHz |
Expansion Module |
| io_type | di_do |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus UDP slave |
Connectors |
| Connectors | RJ45, Terminal block |
Additional Functions |
| Watchdog timer type | Hardware, Software |
System Power Input |
| Input Voltage DC | 10...30 V |
Dimensions and weight |
| Width | 80 mm |
| Depth | 25 mm |
| Height | 98 mm |
Operating Conditions |
| Operating Temperature | -40...70 °C |
Standards and Certifications |
| Certifications | FCC |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 61000-6-2, EN 55011, EN 61000-6-4 |
