Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Digital Input | |
| Total channels of digital input | 6 |
| Type | Dry contact |
| Max frequency | 3 kHz |
| Counter | 3KHz |
Digital Output | |
| Total channels of digital output | 2 |
| Sink/Source | Sink |
| Output voltage | 0~30 V |
| Max. load current | 100 mA |
| Channels | 2 |
| Output frequency range | 0~5 kHz |
Interfaces | |
| RS-485 | 1 |
Antenna characteristics | |
| Cellular interfaces | 4G |
Expansion Module | |
| io_type | di_do |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus RTU slave, Modbus UDP slave, MQTT client |
System Power Input | |
| Input Voltage DC | 10...50 V |
Dimensions and weight | |
| Width | 70 mm |
| Depth | 38 mm |
| Height | 112 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
