Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
CPU | |
| Processor Installed | 16-bit |
Memory | |
| Default on Board Memory | 0 GB |
Installed drive | |
| Flash Memory Capacity | 512 MB |
| EEPROM Memory Capacity | 16 kB |
Software | |
| Programming Method | IF-THEN-ELSE Logic Rules |
Analog Input | |
| Total channels of analog input | 7 |
| Differential channels | 7 |
| Number of Bits | 16 Bit |
| Sampling rate | 12 Hz |
| Thermal resistance | Pt100, Pt1000, Ni120, Cu100, Cu1000 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 72 mm |
| Depth | 35 mm |
| Height | 123 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
