Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
CPU | |
| Processor Installed | 16-bit |
Memory | |
| SRAM | 512 kB |
Installed drive | |
| Flash Memory Capacity | 0.512 MB |
| EEPROM Memory Capacity | 16 kB |
Software | |
| Programming Method | IF-THEN-ELSE Logic Rules |
Digital Input | |
| Total channels of digital input | 6 |
| Type | Wet contact |
| Sink/Source | Sink, Source |
| Level of Logic "0" | 0~4 V |
| Level of Logic "1" | 10~50 V |
| Counter | 50Hz, 16 bit |
| Counter capacity | 16 Bit |
| Max frequency | 0.05 kHz |
Digital Output | |
| Total channels of digital output | 6 |
| Type | Electromagnitic relay |
| Contact rating of relay (Form A) | 5A@250V AC, 5A@30V DC |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 72 mm |
| Depth | 35 mm |
| Height | 123 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
