Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
CPU | |
| Processor Installed | 16-bit |
Memory | |
| Default on Board Memory | 0 GB |
Installed drive | |
| Flash Memory Capacity | 512 MB |
| EEPROM Memory Capacity | 16 kB |
Software | |
| Programming Method | IF-THEN-ELSE Logic Rules |
Digital Input | |
| Total channels of digital input | 8 |
| Type | Dry contact, Wet contact |
| Sink/Source | Sink, Source |
| Level of Logic "0" | 0~4 V |
| Level of Logic "1" | 10~50 V |
| Counter | 50Hz, 16 bit |
Digital Output | |
| Total channels of digital output | 8 |
| Type | Open collector |
| Sink/Source | Source |
| Max. load current | 650 mA |
| Output voltage | 10~40 V |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 76 mm |
| Depth | 38 mm |
| Height | 120 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| EMS | IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5 |
