Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Panel, Wall, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 23.8 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 3000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | AMD Ryzen V1605B |
| Socket | CPU onboard |
| Max CPU frequency | 3.6 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | AMD Radeon RX Vega |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| M.2 | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage External | 1 |
Connectors | |
| Connectors | 2xDB9, 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, Display Port, 2xDisplayPort |
System Power Input | |
| Input Voltage DC | 19...28 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 150 W |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 653.7 mm |
| Height | 412 mm |
| Depth | 121.4 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC, VCCI |
