Construction | |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IPX1 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 19 " |
| Maximum resolution | 1280x1024 Dots |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Core i5-5200U |
| CPU Support Type | Core i3, Core i5, Core i7 |
| Max CPU frequency | 2.7 GHz |
Memory | |
| Form-factor | DDR3L |
| Maximum Memory | 16 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Installed drive | |
| Drive Type | HDD |
| Storage Form-Factor | 2.5" |
| Drive Interface | SATA |
| 1st Storage Capacity | 500 GB |
Extension Slots | |
| PCI Express x4 | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | 2xDB9, 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, 2xDisplayPort |
Dimensions and weight | |
| Width | 430 mm |
| Height | 300 mm |
| Depth | 83 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class B, VCCI |
| Medicine | UL 60601-1, EN 60601-1 |
