Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Panel, Wall, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IPX1 |
| Type | Fan |
Display | |
| Display Type | LED Display |
| Diagonal | 19 " |
| Maximum resolution | 1280x1024 Dots |
| Aspect Ratio | 5:4 |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Coffee Lake |
| Processor Installed | Intel Core i5-9500TE |
| Socket | LGA1151 |
| CPU Support Type | Celeron, Core i5, Core i7, Pentium |
| Max CPU frequency | 3.6 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics 630 |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Drive interfaces | |
| M.2 | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| 1st Storage Capacity | 256 GB |
Extension Slots | |
| Total | 2 |
| PCI Express x4 | 1 |
| M.2 | 1 |
LED / Controls | |
| Controls | On/Off, Control Buttons, Volume Keys |
Connectors | |
| Connectors | 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, 2xDisplayPort, 2xDB9 Male |
System Power Input | |
| Input Voltage DC | 14...19 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 250 W |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 420 mm |
| Height | 450 mm |
| Depth | 84.1 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class B, VCCI |
| Medicine | UL 60601-1, EN 60601-1, UL 60601-1-1-2 |
