Construction | |
| Construction Chassis | Metal Chassis |
CPU | |
| Processor Installed | Intel Core i7 |
| CPU Support Type | Core i3, Core i5, Core i7 |
Chipset | |
| Chipset | Intel HM76 |
Memory | |
| Form-factor | DDR3 |
| ECC | No |
| Default on Board Memory | 2 GB |
| Maximum Memory | 16 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Installed drive | |
| Drive Type | HDD |
| Storage Form-Factor | 2.5" |
| Drive Interface | SATA |
| 1st Storage Capacity | 320 GB |
Extension Slots | |
| PCI Express x16 | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | 6xDB9, DVI-I, 2xRJ45, Mic In, Line Out |
Dimensions and weight | |
| Width | 305 mm |
| Height | 188 mm |
| Depth | 96 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
| Medicine | UL 60601-1, EN 60601-1 |
