Construction | |
| Construction Chassis | Metal Chassis |
CPU | |
| Processor Installed | Intel Core i5-6500TE |
| CPU Support Type | Core i3, Core i5, Core i7 |
| Max CPU frequency | 3.3 GHz |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB v3.x | 3 |
Installed drive | |
| Drive Type | HDD |
| Storage Form-Factor | 2.5" |
| Drive Interface | SATA |
| 1st Storage Capacity | 500 GB |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | 6xDB9, DVI-I, 2xRJ45, Mic In, Line Out, Display Port |
System Power Input | |
| Input Voltage DC | 1.9...28 V |
Dimensions and weight | |
| Width | 306.6 mm |
| Height | 188 mm |
| Depth | 63.6 mm |
Standards and Certifications | |
| Certifications | CE, FCC, VCCI |
| Medicine | UL 60601-1, EN 60601-1 |
