Ethernet | |
| 10/100/1000 Mbit/s | 5 |
Supported Protocols | |
| Protocol Layer 3 | VRRP, RIP V1/V2, OSPF, DVMRP |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3u for 100BaseT(X) |
Digital Input | |
| Total channels of digital input | 4 |
Digital Output | |
| Total channels of digital output | 2 |
Connectors | |
| Connectors | 5xSMA |
Construction | |
| Protection Level of Chassis | IP30, IP40 |
Dimensions and weight | |
| Width | 50 mm |
| Depth | 120 mm |
| Height | 151 mm |
Standards and Certifications | |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8 |
| Freefall | IEC 60068-2-31 |
| Rolling Stock | EN 50155 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27, EN 61373 Category 1 Class B |
