Ethernet | |
| 10/100 Mbit/s | 8 |
| 10/100/1000 Mbit/s | 1 |
| ethernet_poe_100mbit | 8 |
| ethernet_poe_standard | 802_3af |
Interfaces | |
| RS-232/422/485 | 1 |
Supported Protocols | |
| Protocol Layer 3 | VRRP, RIP V1/V2, OSPF |
| IEEE Standard | IEEE 802.1Q for VLAN Tagging, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) |
Connectors | |
| Connectors | DB9, RJ45, SIM Card Slot, 5xSMA |
Construction | |
| Construction Chassis | Metal Chassis, Aluminium Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 200 mm |
| Depth | 126 mm |
| Height | 51 mm |
Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A, CISPR 22 Class |
| EMS | EN 55024, EN 61000-6-2, EN 61000-6-4, EN 55032 |
| Rolling Stock | EN 50155 |
| Safety | EN 60950-1, EN 62368-1 (LVD) |
